OY-YN-V11P
450-512MHz, N-Female
Features:
• Covering 450-512MHz Public Safety Band
• Narrow beam width and High gain with 8 elements
• Suitable for donor antenna and aluminum finished
Description
Electrical Specifications:
| Frequency (MHz) | 450-512 |
| Gain (dBi) | 11.0 ± 1.0 |
| Polarization | Linear / Preinstalled with Vertical Pol. |
| Beamwidth Horizontal (°) | 50 ± 5 |
| Beamwidth Vertical(°) | 48 ± 5 |
| VSWR | ≤ 1.5 |
| Front to Back Ratio (dB) | ≥ 13 |
| Average Power, max (W) | 100 |
| Impedance (ohm) | 50 |
Mechanical Specifications:
Dimension Diameter, Height (in/mm) | 43.31 x 14.17 x 3.35 / 1100 x 360 x 85 |
| Weight w/p mounting kit (lb/kg) | 2.70 / 1.20 |
| Shipping Dimension(in/mm) | 44.09 x 14.76 x 3.54 / 1120 x 375 x 90 |
| Shipping Weight(lb./kg) | 4.45 / 2.02 |
| Radome Material & color | Aluminum finished, White |
| Diameter of the pole mounting pole (in/mm) | ∅1.65 - ∅2.05 / ∅42 - ∅52 |
| Mounting bracket Materials | Zinc Plated Steel |
| Antenna Tilt adjustment (°) | Fixed with 0° |
| Maximum Wind Speed(mph) | 175 |
| Connector type | N-Female |
Environmental Specifications:
| Application | Outdoor |
| Operating Temperature | -40°C to +60°C |
| RoHS | Compliant |
Antenna Pattern:
|
Mechanical Drawing and Installation Guide
| ||
Datasheet: OY-YN-V11P DS 2-0-1_2025_0402 |
