CST-2806-125
CST-2806-150
• IPX8 rated, Waterproof, UV resistant and Ozone resistant.
• Typical Application for N-type, 4.3-10 type and NEX10 connecters.
• Supports Coax 1/2”, 3/8”, 1/4” and 0.141”
• Water seal mastic tape is included for use of 1/4”coax and 0.141” cable.
Description
Electrical Specifications:
| Product Model | CST-2806-125 | CST-2806-150 |
| Pre-shrink diameter. inches [mm] | 1.1 [28] | 1.1 [28] |
| Shrunk diameter. Inches [mm] | 0.24 [6] | 0.24 [6] |
| Length. inches [mm] | 4.92 [125] | 5.91 [150] |
| Cable type | 1/2” Coax, 3/8” Coax. *1/4” Coax and 0.141” with water seal mastic tape | |
| Shrink Method | Pull Cord | |
*Note: Cold Shrink Tube with mastic tape is recommended for 1/4” coax and 0.1441” cable
Specifications:
Item | Condition | Parameters | Test Method |
| Waterproof | Class | IPX8 | IEC 60529:1989+A1:1999+A2:2013 Water immersion test: 1 Meter depth, Duration: 4 hours |
| Physical and mechanical properties | Shore Hardness Tensile Strength Elongation Tear Strength Brittleness temperature by impact |
A/41/1 10.3 MPa 930% 45.8 N/m Compliant | ASTM D2240-15 ASTM D412-15a Method A ASTM D412-15a Method A ASTM D624-00(2012) ASTM D746-14 |
| Flammability | Horizontal burning | HB | UL 94-2013 Rev.6-2016 Section 7 |
| Aging Test | Light aging test-UV exposure | No Crack Discoloration, damage or deformation gray scale: 4-5 | ISO 4892-3:2016 Cycle1& ISO 105-A02:1993/Cor.2:2005 Lamp type: UVA-340, 8hours UV at (60±3)°C BPT,0.76W/(m²×nm)@340nm 4 hours condensation at (50±3)°C BPT Exposure duration: 1000 hours |
| Aging Test | Ozone Aging | No crack, discoloration, damage or deformation | ASTM D1149-16 Method B procedure B1 Temperature: 40±1°C Ozone concentration: 50±5 pphm Exposure duration: 72 hours |
Mechanical specification:
Dimension Diameter, height (in/mm) | 5.9×1.2×1.2 / 150.0×30.0x30.0 |
| Weight(lb./kg) with bracket | 0.1 / 0.04 |
| Shipping Dimension(in/mm) | 5.9×1.2×1.2 / 150.0×30.0x30.0 |
| Shipping Weight(lb./kg) | 0.2 / 0.08 |
Environment & Compliance:
| Application | Outdoor |
| Installation Temperature | -40°C to +60°C |
| Operating Temperature | -60°C to +90°C |
| Storage Temperature | -60°C to +90°C |
| RoHS | Compliant |
| Environment | IPX8 |
| Datasheet: CST-2806 series DS 1-0-0_2025_0211 | ||
