AD-NFAMI



• Low PIM 4.3-10 Male to N-Female adapter

• Low VSWR 1.15

Categories: ,

Description

Electrical Specifications:



 Product ModelAD-NFAMI
 Frequency (MHz)DC-6000
 Insulation Resistance (MΩ)≥ 5000
 Proof Voltage (V)2500
 Insertion Loss (dB)≤0.05 @ 3GHz
 VSWR @ all ports≤ 1.05 @DC-3GHz, ≤ 1.15 @3-6GHz
 PIM (dBc)< -161 @ 2 x 43dBm
 Impedance (ohm)50



Mechanical Specifications:



 Mating Cycles

 500
 Connector Type

4.3-10 Male to N Female

 Outer Conductor Material

 Brass, Copper Tin-Zinc Plated

 Inner Conductor Material

 Spring Copper, Ag Plated

 Nut Material

 Brass, Copper Tin-Zinc Plated

 Insulator Material

 PTFE

 Dimensions

 1.78x0.63x0.63 / 45.0x15.8x15.8

 Weight (lb./kg)

 0.17 / 0.75

 Shipping Dimension (in/mm)

 5.00x10.0 /127.0x254.0

 Shipping Weight (lb./kg)

 0.82 / 0.370



Environmental Specifications:



 ApplicationIndoor/Outdoor
 Operating Temperature-40°C to +85°C
 Relative Humidity (%)≤95
 ROHSCompliant





Outline Drawing:









Datasheet:

AD-NFAMI
